Three Phase Isolation Transformer

 >> Core Advantages

• High-quality silicon steel core + copper windings, enabling effective ground loop elimination & EMI reductio

• Excellent voltage regulation, maintaining stable output under fluctuating input conditions

• Wide range of voltage/power ratings, compliant with international standards (IEC/UL)

• Robust enclosure, ensuring reliable operation in harsh environments

 >> Key Specifications

• Rated Power: 0.5kVA - 2000kVA

• Input Voltage: 208V/400V/480V/690V (customizable for global grids)

• Output Voltage: Customizable based on load requirements (e.g., 220V/380V/415V)

• Frequency: 50Hz/60Hz

• Insulation Class: H/F 级 (180℃/155℃)

• Short-Circuit Withstand Capacity: ≥150% rated current for 30s

• Protection Level: IP20/IP23 (dustproof and splash-proof, customizable for harsh environments)

 >> Typical Applications

• Machinery

• Medical equipment

• Data centers

• Industrial production lines
